Architect W500B

  • Output Power: 486W
  • Modules: 152W red (637nm), 188W green (525nm), 146W blue (465nm)
  • Beam Size: 400mm x 400mm
  • Divergence: 3.4 mrad (full angle)
  • Cooling: Water with 15% glycol mix
  • Control Options: FB4 (ArtNet, DMX), manual
  • Power Needs: Laser projector (100-240V), Chiller (200-230V)
  • Max Power Use: 2,000W (projector), 1,600W (chiller)
  • Operating Temp: 5°C to 40°C
  • Weight: 80kg (projector), 46kg (chiller)
Read more
Product code: N/A
Social share:

Item description

SEO Description: Architect W500B – Powerful Laser for Landmark Illumination

The Architect W500B is a high-power laser system built for lighting up landmarks, buildings, and outdoor spaces. It uses advanced technology to create bright, colorful beams that can be seen from far away. This laser is perfect for adding dramatic effects to iconic structures, enhancing cityscapes, or creating stunning light shows for events. With powerful output and flexible controls, the Architect W500B is ideal for professional lighting designers and event planners.

Exceptional Brightness

The Architect W500B delivers a powerful 486-watt output using RGB laser diodes. It combines 152W red, 188W green, and 146W blue light to create vivid colors and bright beams. Its 130,200 lumens ensure excellent visibility, even in large spaces or outdoors. The beam size of 400mm x 400mm and a 3.4 mrad divergence make it great for precise, focused lighting effects.

Easy Control Options

This laser system gives users flexible control. You can use the built-in FB4 system with ArtNet or DMX for easy integration into lighting setups. The included remote control box allows manual adjustments, and the optional platform provides 350° pan and 126° tilt for beam positioning. The laser also offers full dimming capabilities, letting users adjust brightness to suit different settings.

Built to Last

The Architect W500B is designed to handle tough environments. Its rugged build and water-based cooling system keep it running smoothly in temperatures from 5°C to 40°C. This makes it suitable for both indoor and outdoor use. The system includes a chiller unit, water supply hoses, and other accessories, ensuring reliable operation and quick setup.

Specifications

  • Output Power: 486W
  • Modules: 152W red (637nm), 188W green (525nm), 146W blue (465nm)
  • Beam Size: 400mm x 400mm
  • Divergence: 3.4 mrad (full angle)
  • Cooling: Water with 15% glycol mix
  • Control Options: FB4 (ArtNet, DMX), manual
  • Power Needs: Laser projector (100-240V), Chiller (200-230V)
  • Max Power Use: 2,000W (projector), 1,600W (chiller)
  • Operating Temp: 5°C to 40°C
  • Weight: 80kg (projector), 46kg (chiller)

Conclusion

The Architect W500B provides unmatched performance for professional lighting needs. Its powerful output, flexible controls, and durable design make it a top choice for architectural displays, outdoor events, and landmark illumination. With its bright colors and reliable build, the Architect W500B transforms any space into a dazzling visual experience.
