Create bold, eye-catching beam effects with the 30W LightSpace BeamBar, a professional-grade RGB laser beam fixture built for concerts, festivals, touring productions, nightclubs, and large-scale entertainment events. Combining powerful laser output with advanced scanning technology, this BeamBar delivers razor-sharp aerial effects, dynamic beam movements, and vibrant color mixing that transform any stage or venue.

Featuring an impressive 30 watts of full-color RGB laser power, the BeamBar produces intense red, green, and blue beams that remain bright and visible across large indoor and outdoor spaces. Its precision optics and narrow beam divergence create clean, focused effects, making it ideal for high-impact productions where visibility and performance matter.

Designed for professional lighting and laser designers, the BeamBar includes advanced scanning capabilities that allow for smooth beam sweeps, animated effects, and creative visual displays. The rugged IP65-rated housing protects against dust, rain, and demanding touring conditions, making it a reliable solution for outdoor festivals, concert tours, and permanent venue installations.

Built with high-quality components and an advanced TEC cooling system, the 30W LightSpace USA BeamBar is engineered for long operating hours and dependable performance. Whether used as a standalone effect or integrated into a larger lighting rig, this fixture delivers professional-grade results that captivate audiences.

Specifications

• Laser Power: 30W RGB
• Laser Source: Semiconductor Laser Diodes
• Type: Full-Color RGB Laser Beam Bar
• Suitability: Large-Scale Indoor & Outdoor Displays
• Red Laser: 9,000mW / 638nm
• Green Laser: 10,000mW / 525nm
• Blue Laser: 12,000mW / 450nm
• Beam Divergence: <1.2mrad (Full Angle)
• Modulation: 100KHz Analog
• Modulation Type: Linear Analog Modulation
• Scanner Type: PT-A30HM
• Scanning System: 30Kpps @ 8°
• Scan Angle: 45°
• Control Connections: Ethernet, ArtNet, FB4-DMX
• Ingress Rating: IP65
• Cooling System: TEC Temperature Control
• Operating Temperature: 14°F to 104°F
• Dimensions: 16 in × 10 in × 8 in
• Weight: 46 lbs
• Power Input: AC 100V–240V, 50/60Hz
• Power Consumption: 700W
• Compliance: FDA, CDRH, CE

Perfect For

• Concerts & music festivals
• Touring productions
• Outdoor events
• Nightclubs & entertainment venues
• Stage productions
• Corporate events
• Architectural lighting
• Permanent installations

Key Features

• Powerful 30W RGB laser output
• Bright aerial beams and dynamic scanning effects
• Advanced PT-A30HM scanning system
• FB4-DMX, Ethernet, and ArtNet connectivity
• IP65-rated for indoor and outdoor use
• Smooth beam movement and pixel-style effects
• Professional-grade touring construction
• Advanced TEC cooling for reliable performance
• Ideal for concerts, festivals, and large-scale productions

What’s Included

• Laser Projector
• Heavy-Duty Travel Case
• Power Cord
• Safety Key for Projector
• Metal Safety Wire
• E-Stop Box
• E-Stop Y45 Connector
• E-Stop Safety Key
